4 ohm veya 70V/100V içine Çıkış Gücü 160 Watt
4 kanal mikrofon girişi
Frequency Response (at 1 watt from 4-ohm tap): 70 Hz to 19 kHz +/-1 dB,
(at line out): 20 Hz to 20 kHz +/- 1 dB
Power Bandwidth (at 4-ohm tap, 2 dB below maximum 1 kHz power): 50 Hz to 20 kHz
with < 0.5% THD
Signal to Noise Ratio (ref. to rated power,
master volume at minimum): 85 dB
DC Output Offset < +/-5 mV
THD Less than 0.5% at rated power at 1 kHz
Input Sensitivity (for full output at miximum gain): 800 mV
Input Impedance (nominal) 100 kilohms
Minimum Load Impedance 100V ouput: 160 ohms
70V output: 80 ohms, 4-ohm output: 4/8 ohms
Crosstalk (all controls at "10") -70 dB at 1 kHz
Line Output Level (nominal) 1V into 10 kilohms
AC Line Voltages Available 100V 50/60 Hz,
120V 60Hz, 220V 50/60 Hz, 230V 50/60 Hz, 240V 50/60 Hz
Operating Temperature/Humidity 0 degrees C to 40 degrees C at 95% relative humidity (non-condensing)
Storage Temperature -20 degrees C to 85 degrees C
